Live Video Broadcasting With Membrane

This article is the first in a series on building a fully functional multimedia processing solution with Membrane Framework. The complete source code for this chapter is available at membraneframework-labs/ex_broadcaster. Since the application performs hardware-accelerated video transcoding using Vulkan Video Extensions, running it locally requires a Linux machine with a Vulkan-capable GPU (NVIDIA or AMD) with Mesa drivers and Vulkan Video extension support.

Introduction

We will build a live video broadcasting system: one that ingests an RTMP stream, transcodes it into multiple resolutions to accommodate viewers with varying network conditions, and distributes it globally over HLS. Systems like this are the backbone of platforms such as Twitch — they allow user-generated content to be broadcast simultaneously to thousands of viewers around the world, with the lowest possible end-to-end latency. They are also offered as managed services (e.g. AWS IVS) so that product teams can embed live streaming without building the infrastructure themselves.

Building a reliable broadcasting system is non-trivial. We will show, however, that a solid foundation can be written in Elixir with Membrane Framework — a production-ready one that utilises GPU resources efficiently and scales with demand.

Here is the plan:

Build the multimedia processing pipeline — using existing Membrane components, we will build a pipeline that ingests an RTMP stream, transcodes it with GPU hardware acceleration into multiple resolutions and bitrates, packages each variant as fragmented MP4 (CMAF), and generates a .m3u8 multi-variant playlist so the player can select the appropriate quality based on network conditions.
Wrap the pipeline in an Elixir application to take advantage of OTP supervision trees and runtime configuration.
Prepare a release of the application.
Ensure scalability with clustering on Kubernetes.
Deploy to the cloud with GPU-capable runners for hardware-accelerated encoding and decoding.
Configure a CDN for global distribution.
Add observability to track pipeline health, resource utilization, and stream activity in production.

In this chapter we cover the first three steps.

Prerequisites

In this chapter we will create an Elixir application and run it locally. Since the application will be performing hardware-accelerated video transcoding with the use of Vulkan Video Extensions, you need a Linux machine with a Vulkan-capable GPU (NVIDIA or AMD) with Mesa drivers and Vulkan Video extension support.

For more information, you can take a look at vk-video Rust package which delivers hardware-accelerated transcoding capabilities, which Membrane element uses under the hood. In the next chapters we will focus on deploying the application in the cloud environment so you won’t need to run the application locally, so this requirement won’t apply anymore.

If you are new to Membrane, please take a look at the Getting Started with Membrane guide as it presents basic Membrane concepts and shows how to write your own simple pipelines — we won’t discuss these things in detail in this tutorial. For development purposes, make sure you have FFmpeg installed. If you want to follow the S3 storage section, you will also need an S3 bucket and AWS credentials (AWS_ACCESS_KEY_ID, AWS_SECRET_ACCESS_KEY, AWS_REGION) with write access to that bucket.

System overview

The system consists of three main stages: ingestion, transcoding, and distribution.

Ingestion — the streamer publishes a live video feed over RTMP (Real-Time Messaging Protocol). RTMP is a widely supported streaming protocol, originally developed by Adobe, that carries audio and video data over a persistent TCP connection. The server accepts the incoming TCP connection and extracts the raw audio and video streams from the RTMP envelope.

Transcoding — the incoming stream is typically encoded at a single resolution and bitrate chosen by the streamer. To serve viewers with varying network conditions and device capabilities, we transcode it into multiple output variants (e.g. 1080p, 720p, 480p), each at a different resolution and target bitrate. This is done using the GPU's hardware video acceleration, which is far more efficient than software-based encoding for this kind of workload.

Distribution — the transcoded variants are packaged and delivered to viewers via HLS (HTTP Live Streaming). Each variant is split into short media segments — fragmented MP4 files (fMP4, also known as CMAF — Common Media Application Format) — and an HTTP server exposes two kinds of playlist files alongside them:

a master playlist (.m3u8) listing all available variants with their bandwidth and resolution, so the player can pick the most appropriate one;
a variant playlist (.m3u8) per resolution, listing the individual segments in order so the player can fetch and play them sequentially.

diagram 1.png

Creating a new project

Let’s start by creating a new mix project with the name of your choice:

mix new ex_broadcaster

It will create a template of a Mix project with the basic application structure.

Dependencies

In mix.exs add the required dependencies:

# mix.exs
defp deps do
	[
      {:membrane_core, "~> 1.2"},
      {:membrane_vk_video_plugin, "~> 0.2.1"},
      {:membrane_rtmp_plugin, "~> 0.29.3"},
      {:membrane_http_adaptive_stream_plugin, "~> 0.21.0"},
      {:membrane_mp4_plugin, "~> 0.36.0"},
      {:membrane_h26x_plugin, "~> 0.10.5"},
      {:membrane_aac_plugin, "~> 0.19.0"}
    ]
  end

We need the following packages:

membrane_core — to specify the pipeline structure
membrane_vk_video_plugin — for hardware transcoding capabilities
membrane_rtmp_plugin — for RTMP ingestion source
membrane_http_adaptive_stream_plugin — for HLS playlist generation
membrane_mp4_plugin — for wrapping stream in CMAF container
membrane_h26x_plugin and membrane_aac_plugin — to change the stream structure of video and audio streams (so that they "fit" in CMAF container)

Download the dependencies with:

mix deps.get

Configuration

In config/config.exs let’s add the following entries which we will use later:

# config/config.exs
config :mime, :types, %{
  "application/vnd.apple.mpegurl" => ["m3u8"],
  "video/mp4" => ["m4s", "mp4"],
}

config :ex_broadcaster,
  rtmp_port: 1935,
  segment_duration_sec: 4,
  http_port: 8080,
  max_concurrent_pipelines: 10,
  storage: :file,
  hls_output_dir: "output/hls"

We specify the following entries:

rtmp_port — (TCP) port at which RTMP server will be listening
segment_duration_sec — duration of each fragmented .mp4 CMAF segment (expressed in seconds)
http_port — port at which the generated HLS playlist will be served via HTTP server
max_concurrent_pipelines — limits the number of pipelines which can be run at once
storage — selects the storage backend; :file writes segments to local disk (used here for development)
hls_output_dir — path to the directory where HLS output will be written when storage: :file is used

The provided values are reasonable for a local development, but we will need to change them later, when we deploy the application.

Application startup

In lib/ex_broadcaster/application.ex add the start/2 function:

# lib/ex_broadcaster/application.ex
defmodule ExBroadcaster.Application do
  …
  @max_concurrent_pipelines Application.compile_env(:ex_broadcaster, :max_concurrent_pipelines, 10)

  @impl true
  def start(_type, _args) do
    rtmp_port = Application.get_env(:ex_broadcaster, :rtmp_port, 1935)
    http_port = Application.get_env(:ex_broadcaster, :http_port, 8080)

    children = [
      {Membrane.RTMPServer, port: rtmp_port, handle_new_client: &__MODULE__.handle_new_client/3},
      {DynamicSupervisor, name: __MODULE__.PipelineSupervisor, strategy: :one_for_one},
      {Bandit, plug: ExBroadcaster.HTTPServer, port: http_port}
    ]

    Logger.info("[App] RTMP server listening on port #{rtmp_port}")
    Logger.info("[App] HTTP server listening on port #{http_port}")

    Supervisor.start_link(children, strategy: :one_for_one, name: __MODULE__)
  end
end

On application startup we spawn:

RTMP server listening on chosen port
DynamicSupervisor under which we will spawn the pipelines handling particular streams. Since all its children will be independent from each other, we want it to use :one_for_one supervision strategy.
Bandit HTTP server — a minimal Plug.Router-based server (http_server.ex) that serves HLS playlists and fMP4 segments from the configured hls_output_dir. It sets appropriate cache headers — no-cache for .m3u8 playlists (which change every segment) and a long max-age for segment files (immutable once written) — and allows CORS from any origin so browser-based players like hls.js work without a proxy. We include it here for local development only — in production, a CDN will take over content delivery.

We use :one_for_one supervision strategy to ensure that each child is restarted independently from the other.

RTMP Server

RTMP Server requires providing handle_new_client callback. It’s called each time a new client connects to the server. Let’s implement it:

# lib/ex_broadcaster/application.ex
  def handle_new_client(client_ref, app, stream_key) do
    Logger.info("[App] New RTMP client: app=#{app}, stream_key=#{stream_key}")

    segment_duration_sec = Application.get_env(:ex_broadcaster, :segment_duration_sec, 4)

    pipeline_opts = [
      client_ref: client_ref,
      storage: build_storage(stream_key),
      segment_duration: Membrane.Time.seconds(segment_duration_sec)
    ]

    %{active: active} = DynamicSupervisor.count_children(__MODULE__.PipelineSupervisor)

    if active >= @max_concurrent_pipelines do
      Logger.warning("[App] Rejecting client (stream_key=#{stream_key}): reached limit of #{@max_concurrent_pipelines} concurrent pipelines")
    else
      case DynamicSupervisor.start_child(
             __MODULE__.PipelineSupervisor,
             Supervisor.child_spec({ExBroadcaster.Pipeline, pipeline_opts}, restart: :temporary)
           ) do
        {:ok, _supervisor, pid} ->
          Logger.info("[App] Pipeline started (pid=#{inspect(pid)}) for stream_key=#{stream_key}")

        {:error, reason} ->
          Logger.error("[App] Failed to start pipeline: #{inspect(reason)}")
      end
    end

    Membrane.RTMP.Source.ClientHandlerImpl
  end

  defp build_storage(stream_key) do
    base_dir = Application.get_env(:ex_broadcaster, :hls_output_dir, "output/hls")
    output_dir = Path.join(base_dir, stream_key)
    File.mkdir_p!(output_dir)
    %Membrane.HTTPAdaptiveStream.Storages.FileStorage{directory: output_dir}
  end

In this callback we assert that no more than max_concurrent_pipelines would be running at once after spawning a new pipeline — if not, we attempt to spawn the new pipeline under the DynamicSupervisor spawned in the application. We provide the desired options to the pipeline (we will talk about these options later) and check if the pipeline startup was successful.

build_storage/1 constructs the storage backend for the pipeline. It reads hls_output_dir from config, appends the stream key so that concurrent streams do not overwrite each other's files, ensures the directory exists, and returns a FileStorage struct. Keeping this logic separate from handle_new_client makes it straightforward to swap in a different backend later without touching the rest of the callback.

We use Supervisor.child_spec/2 to set restart: :temporary on the pipeline. Each pipeline is bound to a specific RTMP connection — if it crashes, the TCP connection is gone and the client_ref is stale, so restarting it would be pointless. With restart: :temporary the supervisor simply removes the pipeline when it exits without attempting to restart it.

The last thing we do is to return a module implementing the RTMP client behaviour. In many circumstances we would need to implement this behaviour on our own, but since we want to use the Membrane.RTMP.Server with Membrane.RTMP.Source, we return Membrane.RTMP.Source.ClientHandlerImpl which is a preexisting implementation meant to be used with this common case.

Building the pipeline

Now let’s add a new pipeline module, e.g. ExBroadcaster.Pipeline and a simple start_link/1 implementation that will start the Pipeline module with passed options. See the Membrane.Pipeline docs for the full list of available callbacks.

# lib/ex_broadcaster/pipeline.ex
defmodule ExBroadcaster.Pipeline do
  use Membrane.Pipeline

  require Membrane.Logger, as: Logger

  @variants [
    %{id: :p1080, track_name: "1080p", width: 1920, height: 1080, bitrate: 4_000_000, framerate: {30, 1}},
    %{id: :p720,  track_name: "720p",  width: 1280, height: 720,  bitrate: 2_500_000, framerate: {30, 1}},
    %{id: :p480,  track_name: "480p",  width: 854,  height: 480,  bitrate: 1_000_000, framerate: {30, 1}}
  ]

  def start_link(opts) do
    Membrane.Pipeline.start_link(__MODULE__, opts)
  end
end

We can start implementing Membrane pipeline callbacks.

`handle_init` callback

Let’s start with handle_init:

# lib/ex_broadcaster/pipeline.ex
  @impl true
  def handle_init(_ctx, opts) do
    client_ref = Keyword.fetch!(opts, :client_ref)
    storage = Keyword.fetch!(opts, :storage)
    segment_duration = Keyword.get(opts, :segment_duration, Membrane.Time.seconds(4))

    spec = build_spec(client_ref, storage, segment_duration)

    {[spec: spec], %{}}
  end

This callback reads the desired options:

client_ref — RTMP client reference. Each time a new client connects to the RTMP server you will obtain this reference and you will be able to pass it to the Membrane.RTMP.SourceBin component.
storage — an already-constructed storage struct (built by build_storage/1 in the application). The pipeline passes it straight to the HLS sink and has no knowledge of where data ends up.
segment_duration — duration of each HLS segment. The shorter it is, the smaller streamer → viewer latency you should observe (you cannot reduce it indefinitely as each segment must contain at least one keyframe, and generating keyframes too frequently increases bitrate and encoder load). A value of 2–6 seconds is typical for live streaming.

Then we return the pipeline structure within the spec action. Let’s discuss the pipeline structure (and build_spec private function implementation).

Pipeline structure

Each ExBroadcaster.Pipeline is a static Membrane pipeline built entirely in handle_init/2. The topology has two branches coming out of the RTMP source — one for video, one for audio — that converge into per-variant CMAF muxers before reaching the shared HLS sink.

diagram 2.png

A few things worth noting:

Two H264 parsers per video path — the first one (H264in) converts the incoming stream to Annex B byte-stream format required by the transcoder; the second ones (H264out*) convert each transcoder output back to the avc1 packetized format required by the CMAF container. They are completely separate element instances with different configurations.
Membrane.Tee for audio fan-out — audio is decoded only once and replicated to each CMAF muxer via dynamic output pads. There is no audio re-encoding.
One CMAF.Muxer per variant — each muxer receives exactly one video pad and one audio pad, producing a single interleaved fMP4 track that HLS expects.
Dynamic pads on Transcoder and Tee — output pads are opened at link time with via_out(Pad.ref(:output, id), ...), passing encoding parameters (resolution, bitrate, scaling algorithm) as pad options to the transcoder.

`build_spec/3`

# lib/ex_broadcaster/pipeline.ex
  defp build_spec(client_ref, storage, segment_duration) do
    rtmp_source =
      child(:rtmp_source, %Membrane.RTMP.SourceBin{client_ref: client_ref})

    video_branch =
      get_child(:rtmp_source)
      |> via_out(:video)
      |> child(:h264_parser, %Membrane.H264.Parser{
        output_alignment: :au,
        output_stream_structure: :annexb
      })
      |> child(:transcoder, Membrane.VKVideo.Transcoder)

    audio_branch =
      get_child(:rtmp_source)
      |> via_out(:audio)
      |> child(:aac_parser, %Membrane.AAC.Parser{out_encapsulation: :none, output_config: :esds})
      |> child(:audio_tee, Membrane.Tee)

    hls_sink =
      child(:hls_sink, %HTTPAdaptiveStream.Sink{
        manifest_config: %HTTPAdaptiveStream.Sink.ManifestConfig{
          name: "index",
          module: HTTPAdaptiveStream.HLS
        },
        track_config: %HTTPAdaptiveStream.Sink.TrackConfig{},
        storage: storage
      })

    variant_specs = Enum.flat_map(@variants, &build_variant_spec(&1, segment_duration))

    [rtmp_source, video_branch, audio_branch, hls_sink | variant_specs]
  end

build_spec constructs the pipeline topology as a list of linked element chains which Membrane will wire together:

rtmp_source — Membrane.RTMP.SourceBin receives the incoming RTMP connection identified by client_ref and demuxes it, exposing separate :video and :audio output pads.
video_branch — takes the raw H.264 video, runs it through Membrane.H264.Parser (reformatting to Annex B, AU-aligned) to produce a stream the transcoder can consume, then hands it off to Membrane.VKVideo.Transcoder for GPU-accelerated re-encoding.
audio_branch — takes the AAC audio stream, parses it into raw ADTS-stripped frames with ESDS config, then feeds it into a Membrane.Tee so the single audio stream can be fanned out to all resolution variants without re-encoding.
hls_sink — HTTPAdaptiveStream.Sink collects CMAF tracks from all variants and writes fMP4 segments plus a multi-variant index.m3u8 playlist via the provided storage backend.

Apart from there there we define variant_specs — one spec per entry in @variants, built by build_variant_spec/2 (covered in the next section). Each variant connects a transcoder output pad and a tee output pad into a shared CMAF muxer, which feeds its track into the HLS sink.

`build_variant_spec/2`

build_variant_spec/2 is called once per entry in @variants and returns two linked element chains — one for video, one for audio — that together form a single resolution variant:

# lib/ex_broadcaster/pipeline.ex
  defp build_variant_spec(variant, segment_duration) do
    %{id: id, track_name: name, width: w, height: h, bitrate: br, framerate: fps} = variant

    video_to_muxer =
      get_child(:transcoder)
      |> via_out(Pad.ref(:output, id),
        options: [
          width: w,
          height: h,
          tune: :low_latency,
          rate_control:
            {:constant_bitrate,
             %VKVideo.Encoder.ConstantBitrate{
               bitrate: br
             }},
          scaling_algorithm: :bilinear
        ]
      )
      |> child({:h264_parser_out, id}, %Membrane.H264.Parser{
        output_alignment: :au,
        output_stream_structure: :avc1
      })
      |> via_in(Pad.ref(:input, {:video, id}))
      |> child({:cmaf_muxer, id}, %CMAFMuxer{segment_min_duration: segment_duration})
      |> via_in(Pad.ref(:input, id),
        options: [
          track_name: name,
          segment_duration: segment_duration,
          max_framerate: fps
        ]
      )
      |> get_child(:hls_sink)

    audio_to_muxer =
      get_child(:audio_tee)
      |> via_out(Pad.ref(:output, id))
      |> via_in(Pad.ref(:input, {:audio, id}))
      |> get_child({:cmaf_muxer, id})

    [video_to_muxer, audio_to_muxer]
  end

The video chain (video_to_muxer) starts from the transcoder. Each output pad is opened with via_out(Pad.ref(:output, id), options: [...]), passing the encoding parameters for this variant: target resolution, constant bitrate, low-latency tuning, and bilinear scaling. The re-encoded H.264 stream is then parsed a second time — this time reformatted to avc1 stream structure required by the CMAF container — before being muxed into {:cmaf_muxer, id}. The muxer output is then linked into the shared :hls_sink, with per-track metadata such as track_name and max_framerate passed via via_in options.

The audio chain (audio_to_muxer) is simpler: it taps the :audio_tee at a dynamic output pad keyed by id and feeds directly into the same {:cmaf_muxer, id} that the video chain already created. This means a single CMAF muxer produces one interleaved audio+video track per variant, which is exactly what HLS adaptive streaming expects.

Self-termination of the pipeline

We need to add handle_element_end_of_stream callback to ensure proper termination of the pipeline when the stream ends:

# lib/ex_broadcaster/pipeline.ex
  @impl true
  def handle_element_end_of_stream(:hls_sink, _pad, _ctx, state) do
    Logger.info("HLS sink finished. Terminating pipeline.")
    {[terminate: :normal], state}
  end

  def handle_element_end_of_stream(_child, _pad, _ctx, state) do
    {[], state}
  end

We only need to terminate: normal when the end-of-stream signal arrives at :hls_sink sink element.

Running the application

Now our pipeline is ready for running. In development environment we can do:

mix run --no-halt

Then we can start a test stream with FFmpeg on rtmp://localhost:1935/ex_broadcaster/key:

ffmpeg -re -f lavfi -i testsrc=size=1280x720:rate=30 -f lavfi -i sine=frequency=1000 -c:v libx264 -preset veryfast -tune zerolatency -pix_fmt yuv420p -c:a aac -f flv rtmp://localhost:1935/ex_broadcaster/key

The HLS output will be written to output/hls/key/ and served by the built-in HTTP server at:

http://localhost:8080/key/index.m3u8

You can open this URL directly in a browser with native HLS support (e.g. Safari or Chrome). Alternatively, paste it into the hls.js demo player (local HTTP server is configure to allow all CORS origins). You should be able to see that the resolution changes throughout based on your network condition or even manually change it.

Adding S3 storage

The file-based storage works well for local development, but for production we want to upload segments directly to AWS S3 so they can be served by a CDN. Because the pipeline accepts a plain storage struct and knows nothing about where data lands, adding a second backend requires no changes to the pipeline at all.

Dependencies

Add ex_aws_s3, and hackney (the HTTP client ExAws uses) to mix.exs:

# mix.exs
{:ex_aws_s3, "~> 2.5"},
{:hackney, ">= 0.0.0"}

Implementing the storage

Create lib/ex_broadcaster/storages/s3_storage.ex and implement the Membrane.HTTPAdaptiveStream.Storage behaviour. The behaviour requires two callbacks: store/6 for writing a file and remove/4 for deleting one. Each file is stored at <prefix>/<name> inside the bucket, where the prefix is set per-stream so concurrent streams do not collide.

# lib/ex_broadcaster/storages/s3_storage.ex
defmodule ExBroadcaster.Storages.S3Storage do
  @behaviour Membrane.HTTPAdaptiveStream.Storage

  require Logger

  @enforce_keys [:bucket, :prefix]
  defstruct @enforce_keys

  @impl true
  def init(%__MODULE__{} = config), do: config

  @impl true
  def store(_parent_id, name, content, _metadata, _ctx, %{bucket: bucket, prefix: prefix} = state) do
    key = prefix <> "/" <> name

    case bucket |> ExAws.S3.put_object(key, content) |> ExAws.request() do
      {:ok, _} -> {:ok, state}
      {:error, reason} ->
        Logger.error("S3 upload failed for #{key}: #{inspect(reason)}")
        {{:error, reason}, state}
    end
  end

  @impl true
  def remove(_parent_id, name, _ctx, %{bucket: bucket, prefix: prefix} = state) do
    key = prefix <> "/" <> name

    case bucket |> ExAws.S3.delete_object(key) |> ExAws.request() do
      {:ok, _} -> {:ok, state}
      {:error, reason} ->
        Logger.warning("S3 delete failed for #{key}: #{inspect(reason)}")
        {{:error, reason}, state}
    end
  end
end

init/1 is called once by the HLS sink before streaming starts and simply returns the config struct as state. store/6 and remove/4 are then called for every segment and manifest file as the stream progresses.

AWS credentials and region are resolved by ExAws from the environment in the usual way — AWS_ACCESS_KEY_ID, AWS_SECRET_ACCESS_KEY, AWS_REGION environment variables, an instance role, or entries in config/runtime.exs.

Selecting the backend

Update config/config.exs to add the S3-specific keys alongside the existing ones:

# config/config.exs
config :ex_broadcaster,
  ...
  storage: :file,        # change to :s3 for production
  hls_output_dir: "output/hls",
  s3_bucket: "your-bucket-name",
  s3_prefix: "hls"

Now let's update build_storage/1 function in Application to handle both values of storage: — it needs to construct either a %FileStorage{} or a %S3Storage{}:

# lib/ex_broadcaster/application.ex
defp date_path do
  %{year: y, month: m, day: d, hour: h} = DateTime.utc_now()
  "#{y}/#{m}/#{d}/#{h}"
end

defp build_storage(stream_key) do
  case Application.get_env(:ex_broadcaster, :storage, :file) do
    :s3 ->
      bucket = Application.fetch_env!(:ex_broadcaster, :s3_bucket)
      prefix = Application.get_env(:ex_broadcaster, :s3_prefix, "hls")
      %S3Storage{bucket: bucket, prefix: Enum.join([prefix, date_path(), stream_key], "/")}

    :file ->
      base_dir = Application.get_env(:ex_broadcaster, :hls_output_dir, "output/hls")
      output_dir = Path.join(base_dir, stream_key)
      File.mkdir_p!(output_dir)
      %FileStorage{directory: output_dir}
  end
end

The date_path/0 helper builds a year/month/day/hour path segment from the current UTC time, so each stream is stored under a time-partitioned prefix — e.g. hls/2026/4/8/14/my-stream/. This makes it easy to find recordings by time and to apply S3 lifecycle rules per time window.

Switching to S3 in production is then a single config change — or, more practically, driven by an environment variable in config/runtime.exs:

# config/runtime.exs
import Config

# we need to tell ex_aws to read region from AWS_REGION env
config :ex_aws,
  region: {:system, "AWS_REGION"}

config :ex_broadcaster,
  storage: if(System.get_env("S3_BUCKET"), do: :s3, else: :file),
  s3_bucket: System.get_env("S3_BUCKET", ""),
  s3_prefix: System.get_env("S3_PREFIX", "hls")

Building a release

For deployment outside the development environment, we can now build a self-contained release with:

MIX_ENV=prod mix release

This compiles the application and bundles it together with the Erlang runtime into _build/prod/rel/ex_broadcaster/. The release can then be started on any compatible machine without Elixir or Mix installed:

_build/prod/rel/ex_broadcaster/bin/ex_broadcaster start

Before doing so, create an S3 bucket in your preferred region and make sure you have AWS credentials with write access to it. Then set the AWS_ACCESS_KEY_ID, AWS_SECRET_ACCESS_KEY, AWS_REGION, S3_BUCKET, and S3_PREFIX environment variables before starting the application.

When you start streaming, fMP4 segments and the live HLS playlist will appear in your bucket under $S3_PREFIX/<year>/<month>/<day>/<hour>/<stream_key>/index.m3u8. The playlist is a live HLS playlist — it is updated by the pipeline as each new segment is written, so a player can begin playback before the stream ends.

Live Video Broadcasting: From Scratch to Production With Membrane

Live Video Broadcasting: From Scratch to Production With Membrane

Introduction

Prerequisites

System overview

Creating a new project

Dependencies

Configuration

Application startup

RTMP Server

Building the pipeline

`handle_init` callback

Pipeline structure

`build_spec/3`

`build_variant_spec/2`

Self-termination of the pipeline

Running the application

Adding S3 storage

Dependencies

Implementing the storage

Selecting the backend

Building a release

Live Video Broadcasting: From Scratch to Production With Membrane

Live Video Broadcasting: From Scratch to Production With Membrane

Introduction

Prerequisites

System overview

Creating a new project

Dependencies

Configuration

Application startup

RTMP Server

Building the pipeline

handle_init callback

Pipeline structure

build_spec/3

build_variant_spec/2

Self-termination of the pipeline

Running the application

Adding S3 storage

Dependencies

Implementing the storage

Selecting the backend

Building a release

`handle_init` callback

`build_spec/3`

`build_variant_spec/2`
